第一段：背景
第二段：问题
那么既然现在MySQL的DDL这么快,我们是不是随便什么时候都可以去数据库中对表进行DDL呢?其实不是的,即使是Online DDL也要在业务低峰期进行.如果在对表进行Online DDL的时候刚好这个表有个慢查询在执行,那么DDL语句将等待这个查询的元数据锁（metadata_lock）,后续对这个表的所有DML语句都将被这个DDL阻塞,进而很容易造成连环堵塞和CPU飙升的状况,对业务系统产生极大的影响.
第三段：实验
下面,将实际演示一下Online DDL引发的阻塞问题：
会话A：开启一个事务,执行一条select不提交,那这个事务将一直持有表notest的元数据锁.
mysql>?begin; Query?OK,?0?rows?affected?(0.00?sec) mysql>?select?*?from?test.notest?where?id=1; Empty?set?(0.00?sec)
会话B：对表进行加列的DDL操作,可以看到该操作被堵塞,其实就是在等待会话A的元数据锁.
mysql>?alter?table?test.notest?add?age?int;
会话C、会话D：再开启两个会话,对该表进行简单的查询,该查询也在等待锁,没有返回结果.
mysql>?select?*?from?test.notest;
查看processlist,可以看到ddl和dml都在等待表的元数据锁：
mysql>?show?processlist; +-------+-----------------+--------------------+------+------------------+-------+-----------------------------------------------------------------+-------------------------------------+ |?Id?|?User??|?Host???|?db?|?Command??|?Time?|?State???????????|?Info??????| +-------+-----------------+--------------------+------+------------------+-------+-----------------------------------------------------------------+-------------------------------------+ |??5?|?event_scheduler?|?localhost??|?NULL?|?Daemon???|?15986?|?Waiting?on?empty?queue???????|?NULL??????| |?33?|?repl??|?10.2.111.193:33644?|?NULL?|?Binlog?Dump?GTID?|?15964?|?Source?has?sent?all?binlog?to?replica;?waiting?for?more?updates?|?NULL??????| |?17805?|?root??|?localhost??|?test?|?Query??|?64?|?Waiting?for?table?metadata?lock??????|?alter?table?test.notest?add?age?int?| |?17814?|?root??|?localhost??|?test?|?Sleep??|?346?|????????????|?NULL??????| |?17973?|?root??|?localhost??|?NULL?|?Sleep??|?368?|????????????|?NULL??????| |?18370?|?root??|?localhost??|?NULL?|?Query??|?42?|?Waiting?for?table?metadata?lock??????|?select?*?from?test.notest???| |?18393?|?root??|?localhost??|?NULL?|?Query??|?24?|?Waiting?for?table?metadata?lock??????|?select?*?from?test.notest???| |?18418?|?root??|?localhost??|?NULL?|?Query??|??0?|?init??????????|?show?processlist????| +-------+-----------------+--------------------+------+------------------+-------+-----------------------------------------------------------------+-------------------------------------+ 8?rows?in?set?(0.00?sec)
查看元数据锁监控表performance_schema.metadata_locks表信息,可以看到当前数据库中存在的元数据锁已经元数据锁的对象和锁类型（在MySQL中,为了提高数据库的并发度,元数据锁被细分为了11种类型）.可以看到DDL语句给表带来的元数据锁类型为EXCLUSIVE,元数据EXCLUSIVE锁被持有期间任何其他的元数据锁都不能被授予,所以就阻塞了后续对表的所有DML操作,也包括select.
mysql>?select?*?from?performance_schema.metadata_locks; +-------------+--------------------+----------------+-------------+-----------------------+---------------------+---------------+-------------+--------------------+-----------------+----------------+ |?OBJECT_TYPE?|?OBJECT_SCHEMA?|?OBJECT_NAME?|?COLUMN_NAME?|?OBJECT_INSTANCE_BEGIN?|?LOCK_TYPE???|?LOCK_DURATION?|?LOCK_STATUS?|?SOURCE???|?OWNER_THREAD_ID?|?OWNER_EVENT_ID?| +-------------+--------------------+----------------+-------------+-----------------------+---------------------+---------------+-------------+--------------------+-----------------+----------------+ |?TABLE??|?test???|?notest??|?NULL??|??140139226332208?|?SHARED_READ??|?TRANSACTION?|?GRANTED??|?sql_parse.cc:6085?|???18049?|???5?| |?GLOBAL?|?NULL???|?NULL???|?NULL??|???132890928?|?INTENTION_EXCLUSIVE?|?STATEMENT??|?GRANTED??|?sql_base.cc:5476?|???17881?|???21?| |?BACKUP?LOCK?|?NULL???|?NULL???|?NULL??|???123469776?|?INTENTION_EXCLUSIVE?|?TRANSACTION?|?GRANTED??|?sql_base.cc:5483?|???17881?|???21?| |?SCHEMA?|?test???|?NULL???|?NULL??|???125839424?|?INTENTION_EXCLUSIVE?|?TRANSACTION?|?GRANTED??|?sql_base.cc:5463?|???17881?|???21?| |?TABLE??|?test???|?notest??|?NULL??|???125839520?|?SHARED_UPGRADABLE?|?TRANSACTION?|?GRANTED??|?sql_parse.cc:6085?|???17881?|???21?| |?TABLESPACE?|?NULL???|?test/notest?|?NULL??|???130194048?|?INTENTION_EXCLUSIVE?|?TRANSACTION?|?GRANTED??|?lock.cc:808??|???17881?|???21?| |?TABLE??|?test???|?#sql-5246_458d?|?NULL??|???124845680?|?EXCLUSIVE???|?STATEMENT??|?GRANTED??|?sql_table.cc:17024?|???17881?|???21?| |?TABLE??|?test???|?notest??|?NULL??|???126124176?|?EXCLUSIVE???|?TRANSACTION?|?PENDING??|?mdl.cc:3754??|???17881?|???22?| |?TABLE??|?test???|?notest??|?NULL??|??140138743169920?|?SHARED_READ??|?TRANSACTION?|?PENDING??|?sql_parse.cc:6085?|???18446?|???3?| |?TABLE??|?performance_schema?|?metadata_locks?|?NULL??|??140138825181536?|?SHARED_READ??|?TRANSACTION?|?GRANTED??|?sql_parse.cc:6085?|???17890?|???26?| |?TABLE??|?test???|?notest??|?NULL??|??140139414229984?|?SHARED_READ??|?TRANSACTION?|?PENDING??|?sql_parse.cc:6085?|???18469?|???3?| +-------------+--------------------+----------------+-------------+-----------------------+---------------------+---------------+-------------+--------------------+-----------------+----------------+ 11?rows?in?set?(0.00?sec)
同时,可以查询sys.schema_table_lock_waits视图,该视图显示了当前元数据锁的锁等待信息.可以看到等待和阻塞的会话ID,并且kill掉阻塞会话的语句也直接在sql_kill_blocking_connection这一列给出来了,非常方便.
mysql>?select?*?from?sys.schema_table_lock_waits; +---------------+-------------+-------------------+-------------+-----------------+-------------------+-----------------------+-------------------------------------+--------------------+-----------------------------+-----------------------------+--------------------+--------------+------------------+--------------------+------------------------+-------------------------+------------------------------+ |?object_schema?|?object_name?|?waiting_thread_id?|?waiting_pid?|?waiting_account?|?waiting_lock_type?|?waiting_lock_duration?|?waiting_query?????|?waiting_query_secs?|?waiting_query_rows_affected?|?waiting_query_rows_examined?|?blocking_thread_id?|?blocking_pid?|?blocking_account?|?blocking_lock_type?|?blocking_lock_duration?|?sql_kill_blocking_query?|?sql_kill_blocking_connection?| +---------------+-------------+-------------------+-------------+-----------------+-------------------+-----------------------+-------------------------------------+--------------------+-----------------------------+-----------------------------+--------------------+--------------+------------------+--------------------+------------------------+-------------------------+------------------------------+ |?test??|?notest?|???17881?|??17805?|?root@localhost?|?EXCLUSIVE??|?TRANSACTION???|?alter?table?test.notest?add?age?int?|????53?|?????0?|?????0?|???18049?|??17973?|?root@localhost?|?SHARED_READ??|?TRANSACTION??|?KILL?QUERY?17973??|?KILL?17973????| |?test??|?notest?|???18446?|??18370?|?root@localhost?|?SHARED_READ??|?TRANSACTION???|?select?*?from?test.notest???|????47?|?????0?|?????0?|???18049?|??17973?|?root@localhost?|?SHARED_READ??|?TRANSACTION??|?KILL?QUERY?17973??|?KILL?17973????| |?test??|?notest?|???18469?|??18393?|?root@localhost?|?SHARED_READ??|?TRANSACTION???|?select?*?from?test.notest???|????44?|?????0?|?????0?|???18049?|??17973?|?root@localhost?|?SHARED_READ??|?TRANSACTION??|?KILL?QUERY?17973??|?KILL?17973????| |?test??|?notest?|???17881?|??17805?|?root@localhost?|?EXCLUSIVE??|?TRANSACTION???|?alter?table?test.notest?add?age?int?|????53?|?????0?|?????0?|???17881?|??17805?|?root@localhost?|?SHARED_UPGRADABLE?|?TRANSACTION??|?KILL?QUERY?17805??|?KILL?17805????| |?test??|?notest?|???18446?|??18370?|?root@localhost?|?SHARED_READ??|?TRANSACTION???|?select?*?from?test.notest???|????47?|?????0?|?????0?|???17881?|??17805?|?root@localhost?|?SHARED_UPGRADABLE?|?TRANSACTION??|?KILL?QUERY?17805??|?KILL?17805????| |?test??|?notest?|???18469?|??18393?|?root@localhost?|?SHARED_READ??|?TRANSACTION???|?select?*?from?test.notest???|????44?|?????0?|?????0?|???17881?|??17805?|?root@localhost?|?SHARED_UPGRADABLE?|?TRANSACTION??|?KILL?QUERY?17805??|?KILL?17805????| +---------------+-------------+-------------------+-------------+-----------------+-------------------+-----------------------+-------------------------------------+--------------------+-----------------------------+-----------------------------+--------------------+--------------+------------------+--------------------+------------------------+-------------------------+------------------------------+ 6?rows?in?set?(0.01?sec)
第四段：结论
通过以上的实验,可以得出结论,如果在对表进行Online DDL时,该表上存在元数据锁,那么DDL将一直等待元数据锁释放,直到超过参数lock_wait_timeout的超时时间,并且该DDL会阻塞后续对该表的所有操作.所以呢,即使现在支持instant算法的Online DDL可以秒加列,也要在业务低峰期进行,并且执行DDL前,最好查询一下performance_schema.metadata_locks,检查是否存在元数据锁.
